[MF100-1112-A03100A] 2.54 mm pitch SMT spring test probes connector

[MF100-1112-A03100A] 2.54 mm pitch SMT spring test probes connector

  • Insulator:Black high temperature plastic UL94 V-0

  • Pin:Brass Au over Ni

  • Any other materials and dimension depends on customers’ demand

  • RoHs Compliant and Halogen-free

Inquiry Now

Description

2.54 mm pitch SMT spring test probes connector.The conector is maximum continuity, precision-machined gold-plated components and a low-resistance spring maintain a consistent electrical path. Our pogo pin conectors are RoHs compliant and halogen-free. Excellent performance and specially suitable for High-Frequency application.

Advantages of our company

  • World’s first manufacturer developed large current pogo pin with 20A, 15A series has been mass produced
  • World’s second manufacturer developed 1.27 pitch pogo pin connector
  • Asia’s first manufacturer achieved compression mechanical 1 million life times
  • Asia’s first professional medical, industrial, special industries such as automobile industry suppliers
  • China’s first pogo pin product with magnet combined connector manufacturer and own most solutions

Details of 2.54 mm pitch SMT spring test probes connector


 2.54 mm pitch SMT spring test probes connector

Download PDF

Part No. MF100-1112-A03100A
Materials Insulator Black high (265℃) plastics UL94 V-0
Plunger Brass Au over Ni
Barrel Brass Au over Ni
Spring SUS surface treatment
Mechanical Contact force 90g+20% at 1.0mm working stroke
Full stroke 1.40mm
Life test 100,000 cycles
Electrical Rated current and voltage DC 12V,1A max
Contact-resistance 50  milliohms max .The contact is more stable and the conductivity will be better

Customized service

Learn more about How to order special pogo pin, If you have special requirements please contact us

Learn more type of Pogo pin

 SMT/SMD  DIP  Right angle  Double head  Solder cup  Screw thread
