- Barrel & plunger: Brass/Be-Cu/Phosphor bronze
- Plating: Gold plated (According to customer requirements)
- Spring: SUS surface treatment
- Life test:20,000 cycles
- Rated current & voltage: DC 12V; 2A
[BP00312] Pogo pin right angle 2a manufacturer
Description
Pogo pin right angle 2a manufacturer in China. Our right angle pogo pin or spring loaded pins, is reliable quality and quick to install. Bending tail design of barrel of these right angle pogo pin offers engineers to have more choices on space adjustment. Pogo pin is a special connector the basic structure of a turning barrel, a cutting plunger and Compression spring. The barrel tube mouth edge, keep the plunger in the barrel, by the spring provide contact force the Electrical connections between plunger and the butt joint parts. You may like Types of Pogo pin and their uses
Specification of Pogo pin right angle 2a
|
Part No. | BP00312 | |
| Materials | Plunger | Brass 3u” Au over 50u” Ni | |
| Barrel | Brass 1u” Au over 50u” Ni | ||
| Spring | SUS 304 3u” Au | ||
| Mechanical | Contact force | 200g±20% at 1.5mm working stroke | |
| Full stroke | 1.5mm | ||
| Life test | 20,000 cycles | ||
| Electrical | Rated current and voltage | DC 12V; 2A | |
| Contact-resistance | 50 milliohm Max | ||
Drawing of Pogo pin right angle 2a
To ensure the best usage, please operate it based on the working height. Based on the engineering drawings, shall not exceed the maximum allowed compression.
Customized service
The unit of A, B, C, D, E, F, G and Stroke is mm
| Part NO. | A | B | C | D | E | F | G | H | Stroke(mm) | Force(g) | Current(A) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BP00311 | 6.80 | 4.80 | 0.80 | 4.50 | 3.00 | 2.00 | 1.85 | / | 1.50 | 300 | 2 |  |
| BP00322 | 6.80 | 4.80 | 0.80 | 4.50 | 3.00 | 2.00 | 1.85 | / | 1.00 | 90 | 3 | |
| BP09401 | 7.10 | 4.00 | 1.00 | 3.50 | 2.50 | 1.80 | 7.50 | 14.00 | 3.00 | 120 | 1 | |
| BP09402 | 7.10 | 4.00 | 1.00 | 3.50 | 2.50 | 1.80 | 5.00 | 9.00 | 3.00 | 120 | 1 | |
| BP10111 | 5.00 | 2.85 | / | / | 2.00 | 1.50 | 0.50 | 15.95 | 1.20 | 110 | 2 | |
| BP10121 | 5.00 | 2.85 | / | / | 2.50 | 1.90 | 0.50 | 17.55 | 1.50 | 110 | 2 | |
| BP10131 | 4.90 | 2.85 | / | / | 2.00 | 1.50 | 0.50 | 10.35 | 1.20 | 120 | 2 | |
| BP30841-06254E0A | 8.00 | 5.30 | / | / | / | 1.00 | 2.00 | 5.00 | 1.00 | 70 | 3 | |
| BP32011-04508E0A | 7.00 | 5.30 | / | / | / | 1.00 | 2.00 | 3.00 | 1.00 | 70 | 3 | |
| BP41611 | 5.50 | 4.30 | 0.40 | 1.80 | 1.48 | 1.00 | 2.00 | 8.00 | 1.00 | 70 | 3 | |
| BP43401-06254H0B | 3.60 | 2.90 | / | 1.50 | 1.80 | / | 2.00 | 4.50 | / | / | 1 | |
| BP43411-06254H0A | 6.10 | 4.60 | 0.80 | 1.50 | 1.50 | 1.00 | 2.00 | 3.00 | 1.00 | 70 | 1 | |
| BP47811 | 8.00 | 6.80 | 0.40 | 1.80 | 1.48 | 1.00 | 2.00 | 3.00 | 1.00 | 70 | 3 | |
Learn more about How to order special pogo pin, If you have special requirements please contact us
You may like our customized pogo pin connector
Application of Pogo pin right angle 2a
 |
 |
 |
||
Pogo pin Connectors developed & produced by CFE, can be applied to unlimited applications. Below are just some of the examples of how the products can be used Please feel free to contact CFE for more details
- Consumer electronics products/PCB board
- Digital camera/Medical products/ Printer cartridges
- Golf handle/ Electric vehicles/ Telephony applications
- Cardiac defibrillator/Car charging /Air purifier
- LED flat luminaries/LED flash light/Tablet/Laptop/PC
- Power bank/ Digital product/ Small household electrical application
- Charging products/Signal transmission products etc
